Drive2 Fleet
The all new Drive2 features bold new colors and new body styling, it’s more luxurious, and offers more value than ever. And as if that weren’t enough, we’ve built in new features and equipment designed specifically for your player’s comfort and convenience – in fact, after your players experience the difference, they won’t want to play without it.
Need more information?
Features
Frame - HybriCore™ Chassis features a robotic welded automotive ladder-style steel frame protected with a multi-step full-immersion phosphate treatment, electro-deposition epoxy-based coating, and an electrostatic applied polyester/urethane powder topcoat.
Body - Mold-in Polypropylene color for White and Beige Color. Custom-formulated thermoplastic olefin painted with a two-part top coat of high-luster automotive-grade polyurethane.
Steering - Self-compensating double reduction helical rack-and-pinion.
Front Wheel Suspension - Tru-Trak II™ fully independent automotive-style strut suspension.
Rear Wheel Suspension - QuieTech EFI and PowerTech AC: Fully independent automotive-style strut suspension. Drive2 EFI and Drive2 AC: Swing arm with coil springs over hydraulic shock absorbers.
Brakes - Self-adjusting mechanical, rear wheel drum brakes.
Bumpers - Front and rear 5 mph energy-absorbing bumpers.
Specifications
| ELECTRIC (POWERTECH AC and POWERTECH LI) | |
| Motor | 48-volt AC Motor |
| Output Rating | 6.7 hp (5.0 kW) |
| Motor Control Unit | Toyota® Industries-built motor controller unit. |
| Batteries | AC - Standard: Six 8-Volt Trojan® T875 AC - Optional: Eight 6-Volt Trojan® T105 or Six 8-Volt Trojan T875 AGM LI - One Lithium Iron Phosphate |
| Charger | AC - Delta-Q Charger |
| GAS (QUIETECH EFI) | |
| Fuel System | EFI - Electronic Fuel Injection |
| Engine Type | Yamaha-built, 357 cc, low-emission single cylinder 60° incline OHV |
| Lubrication System | Splash-style positive oil lubrication |
| Oil Capacity | 1 U.S. quart (1 liter, 1,000 cc) |
| Air Cleaner | Two-stage, urethane-foam pre-cleaner, and high-capacity pleated paper cartridge |
| Cooling System | Forced Cooling |
| Starting System | Starter generator with pedal start system |
| Dry Weight | QuieTech EFI: 714.3 lb (324kg) Drive2 EFI: 681.2 lb (309 kg) PowerTech AC: 617.3 lb (280 kg) Drive2 AC: 595.2 lb (270 kg) |
| Tire Size | 18 x 8.5 - 8 (4-ply rating) |
| Seating Capacity | 2 persons |
| Available Model Colours | Arctic Drift Matte, Glacier, Sunstone, Emerald, Garnet, Moonstone Metallic, Carbon Metallic, Bluestone Metallic, Mica Metallic |
| Available Seat Colours | Standard: Stone Optional: Black |
| Available Suntop Colours | Standard: Stone Optional: Black |
Dimensions
| Overall Length | 93.6 in (238 cm) | |
| Overall Width | 47.3 in (120 cm) | |
| Overall Height (with suntop) | 70.2 in (178 cm) | |
| Wheelbase | 64.4 in (164 cm) | |
| Front Wheel Tread | 34.8 in (88 cm) | |
| Rear Wheel Tread | 38.3 in (97 cm) | |
| Minimum Ground Clearance | 4.3 in (110mm) | |
| Floor Board Height | 12.9 in (33 cm) |
