Drive2 PTV
Why choose between luxury and reliability? With the new Drive2 line of Personal Transportation Vehicles, now you don’t have to. Over 60 years of precision engineering and technological innovations come together in our most beautiful and luxurious personal transportation line to date.
Need more information?
Features
Frame - HybriCore™ Chassis features a robotic welded automotive ladder-style steel frame protected with a multi-step full-immersion phosphate treatment, electrodeposition epoxy-based coating, and an electrostatic applied polyester/urethane powder topcoat.
Body - Mold-in Polypropylene for Glacier color. Custom-formulated thermoplastic olefin painted with a two-part top coat of high-luster automotive-grade polyurethane.
Steering - Self-compensating double reduction helical rack-and-pinion.
Front Wheel Suspension - Tru-Trak II™ fully independent automotive-style strut suspension.
Rear Wheel Suspension - MY16-20 models: Unit swing arm with coil springs over hydraulic shock absorbers. MY21-25 models: Fully independent automotive-style strut suspension.
Brakes - Self-adjusting mechanical, rear wheel drum brakes.
Bumpers - Front and rear 5 mph energy-absorbing bumpers.
Specifications
| ELECTRIC (POWERTECH AC and POWERTECH LI) | |
| Motor | 48-volt AC Motor |
| Output Rating | 6.7 hp (5.0 kW) |
| Motor Control Unit | Toyota® Industries-built motor controller unit. |
| Batteries | AC - Standard: Six 8-Volt Trojan® T875 AC - Optional: Eight 6-Volt Trojan® T105 or Six 8-Volt Trojan T875 AGM LI - One Lithium Iron Phosphate |
| Charger | AC - Delta-Q Charger |
| GAS (QUIETECH EFI) | |
| Fuel System | EFI - Electronic Fuel Injection |
| Engine Type | Yamaha-built, 357 cc, low-emission single cylinder 60° incline OHV |
| Lubrication System | Splash-style positive oil lubrication |
| Oil Capacity | 1 U.S. quart (1 liter, 1,000 cc) |
| Air Cleaner | Two-stage, urethane-foam pre-cleaner, and high-capacity pleated paper cartridge |
| Cooling System | Forced Cooling |
| Starting System | Starter generator with pedal start system |
| Dry Weight | QuieTech EFI: 751 lb (341kg) PowerTech AC: 665.8 lb (302 kb) |
| Fuel Tank Capacity (Gas) | 5.8 U.S. gal (22 liters) |
| Tire Size | 205/65-10 DOT (4 ply rating) |
| Seating Capacity | 2 persons |
| Available Model Colours | Glacier Metallic: Atomic Flame, Mica, Graphite, Bluestone, Moonstone, Onyx, Aqua Blue, Jasper |
| Available Seat Colours | Standard: Stone Optional: Black |
| Available Suntop Colours | Standard: Stone Optional: Black |
Dimensions
| Overall Length | 93.6 in (238 cm) | |
| Overall Width | 47.3 in (120 cm) | |
| Overall Height (with suntop) | 70.2 in (178 cm) | |
| Wheelbase | 64.4 in (164 cm) | |
| Front Wheel Tread | 35 in (89 cm) | |
| Rear Wheel Tread | 38.7 in (98 cm) | |
| Minimum Ground Clearance | 5.5 in (14 cm) | |
| Floor Board Height | 12.9 in (33 cm) |
