R145DR Tiltback Changer
The R145DR is an automatic tire changer with an innovative electric motor inverter. This inverter regulates the chucking table rotation speed to reduce the stress on the bead and avoid damage to the tire. This tire machine also has a Fast Inflation (FI) configuration.
Need more information?
Features
- 2 position centering lock / 10”-26” range
- Hand controlled bead breaker
- Adjustable tool guide for alloy rim protection
- Bolt caps to prevent hooking of air hoses
- Integrated helper arm included
- Lower bead lifting roller
- Pneumatic top bead pressing tool
- Filter / Tire paste lubricant and brush
Specifications
| Chuck rotation speed (rev/min) | 0-16 rpm / 7,3 rpm (D version) 7.3 rpm (110v version) |
| Maximum torque to chuck | 885 Ft/L bs (1200 Nm) |
| Self-centring lock: external | 10”- 26” |
| Self-centring lock: internal | 12”- 28,5” |
| Tool working span | 8”- 32” |
| Maximum tire diameter | 45” (1143mm) |
| Maximum tire width | 17” (431mm) |
| Bead breaker cylinder power at 145 psi | 6,745 Ft/L lbs (3060 kg) |
| Power supply* (Model 145DR) Motor | 220v / 1Ø / 60 Hz / 1 Hp |
