Page 314 - Q3 2025 Stephenson Equipment Catalogue

HEAT GUNS / FLAMELESS HEAT TOOLS / TORCHES

Propane Torches

MAS-PT-2000SI $90 25
Heavy Duty, High Intensity
VCT-0386-0403 $216 95 Propane Torch Head
• Push button ignition
STK-9 Extreme® Torch • Can be used with Propane (flame burns at 3,600°F)
• BTU MAP-Pro: 1,800 or MAPP Gas (flame burns at 3,730°F)
• 360° swivel tip • Cast aluminum housing
• STK-R Pressure regulator • Safety lock
• ST-3 Tip • CGA-600 Connection • Flame lock push button for continuous use
• Use with standard Propane or MAPP Gas cylinders

MAS-VMAX-550 $366 85

VCT-0386-0851 $265 95 Versatile Propane Torch with
Interchangeable Nozzles
STK-99 Extreme® Torch • Great tool for: burning weeds and stumps,
• BTU MAP-Pro: 1,700 melting snow/ice, softening asphalt, shrink
wrap packaging, searing meats and fish,
• 360° swivel tip lighting fires and charcoal grills, and more...
• STK-R Pressure regulator • Two-step trigger that gives you regular and
• ST-33 Self-lighting tip MAX output on the long barrel nozzle
• CGA-600 connection • Attaches directly to any standard sized portable propane
canister, or to any 5 lb and up tank with a hose adapter
(hose adapter and hose not included)
• Includes: 8" short barrel nozzle, 12" long barrel nozzle,
circular propane tank stand for tall 14.1 oz cylinders

VCT-0386-0860 $90 35

TP-10 Extreme® Pencil Flame Torch VCT-0426-4001 $218 75
• Flame control valve for precise heat adjustments
• Operates on any standard MAP-Pro and SK-7000 Self Lighting Hand Torch
Propane 14.1 oz tank – Propane & MAP/Pro™
• Great for light application jobs • Preset flame
• 180° swivel tip
• Safety trigger lock
• Operates on any standard MAP-Pro and
Propane 1 lb (14.1 oz) tank
• CGA 600 connection

VCT-0386-1295 $745 55
0387-1295
TXK-504 Extreme®
Torch Kit
0387-1297 0387-1293 0387-1299 Kit includes:
• TX-504 Hand torch
EXTREME® Series Self Lighting with T-504 tip
MAP-Pro™ & Propane Torches • Adapter (0386-0508)
• TurboTorch Swirl combustion generates more heat that other hand torches for • Hose (TS-12)
• Regulator (STK-R)
faster brazing times and less gas consumption
• The TX-503 series is a cooler torch, making it ideal for general plumbing jobs • Gas cylinder not included
• The TX-504 series is suitable for HVAC and high capacity applications
Torch
Item # Model Tip Model / Tip Part # Soft Solders Propane Silver Brazes Soft Solders MAP-Pro Silver Brazes
VCT-0386-1297 TX-503 T-503 / #0386-1298 1/8"–2" (3.2-50mm) 1/16"–3/4" (1.6-19mm) 1/8"–3" (3.2-76mm) 1/16"–1" (1.6-25mm) $261.65
VCT-0386-1293 TX-504 T-504 / #0386-1296 3/4"–3" (19-76mm) 1/4"–1" (6.4-25mm) 3/4"–4" (19-102mm) 1/4"–1-1/4" (6.4-32mm) $299.25
VCT-0386-1299 TX-500 T-503 + T-504 1/8"–2" (3.2-50mm) 1/16"–3/4" (1.6-19mm) 1/8"–3" (3.2-76mm) 1/16"–1" (1.6-25mm) $321.15
ProPak #0386-1298 + #0386-1296 3/4"–3" (19-76mm) 1/4"–1" (6.4-25mm) 3/4"–4" (19-102mm) 1/4"–1-1/4" (6.4-32mm)

314 | July – September 2025
