WELDING & SOLDERING

Welding & Cutting Equipment

ESB-0700301082 $1259 05
Rogue EM 140 MIG/MAG
120V Welding Package
• Inverter-based MIG/MAG welding system
• Spool gun ready
• Input: 120VAC ±10%, 1ph, 50/60 Hz
• MIG (GMAW) welding output:
90 A / 18.5 V at 30%, 64 A / 17.2 V at 60%
49 A / 16.5 V at 100%
• Current range: 30 – 140 A • Voltage range: 12 – 22 V
• Max. material thickness: - Mild steel: 24 ga. - 1/4" (0.5-6mm)
- Aluminum: 16 ga. - 1/8" (1.5-3.5mm)
• Wire dim.: - Mild steel & stainless steel: 0.6 – 0.9mm (0.023" – 0.035")
- Cored wire (FCAW) & aluminum: 0.8 – 0.9mm (0.030" – 0.035")
• Max. spool diameter: 100mm & 200mm (4" & 8")

ESB-0700301083 $2193 75

VCT-W1003210 $1366 45 Rogue EM 190 PRO MIG/MAG
230V Welding Package
ES 95i DC TIG and Stick • Inverter-based MIG/MAG welding system
Portable Suitcase Welder, 115VAC • Spool gun ready
• Versatile, multi-process Stick/TIG capability • Input: 230 VAC ±10%, 1, 50/60 Hz
• High 95 Amp welding output • MIG (GMAW) welding output:
• ESAB 95 S inverter welding power source 145 A / 21.25 V at 30%
102 A / 19.1 V at 60%, 79 A / 17.95 V at 100%
• 17V style TIG torch • Current range: 30 – 190 A • Voltage range: 12 – 26 V
• Argon regulator / flow gauge • Max. material thickness: - Mild steel: 24 ga. - 3/8" (0.6-10mm)
• Tweco WeldSkill style electrode holder with 10 ft. (3m) lead - Aluminum: 18 ga. - 3/8" (1.2-10mm)
• Tweco WeldSkill style ground clamp with 10 ft. (3m) lead - Stainless: 20 ga. - 1/4" (1-6mm)
• 20 Amp adapter plug & cable • Wire dim.: - Mild steel & stainless steel: 0.6 – 0.9mm (0.023" –0.035")
- Cored wire (FCAW) & aluminum: 0.8 – 0.9mm (0.030" –0.035")
• 4 general purpose stick electrodes (E6013) • Max. spool diameter: 100mm & 200mm (4" & 8")
• The 95i will not burn 6010 or 6011 electrodes
• The ESAB 95i units are DC only and will not TIG weld aluminum
ESB-0700301085 $3417 55
Rogue EMP 210 PRO Multi-Process
ESB-0700734012 $316 05 MIG/MAG 230V Welding Package
HandyArc 1/8 Stick (SMAW) Welder • Inverter-based welding system
• Inverter-based system • Spool gun ready for MIG aluminum
• Input: 230 VAC ±10%, 1 ph, 50/60 Hz
• Input: 120/240 VAC ±10%, 1Ø, 50/60 Hz • Voltage range: 12– 26 V
• SMAW welding output:
120VAC – 70 A / 22.8 V at 20% • Current range: 30 – 210 A
41 A / 21.7 V at 60% • MIG (GMAW) welding output: 210A/24.5V @ 30%; 136A/20.8V @ 60%
32 A / 21.3 V at 100% 105A/19.2V @ 100%
240VAC – 160 A / 26.4 V at 15% • MMA (SMAW) welding output: 180A/27.2V @ 30%; 116A/24.7V @ 60%
80 A / 23.2 V at 60% 90A/23.6V @ 100%
62 A / 22.5 V at 100% • TIG (GTAW) welding output: 210A/18.0V @ 30%; 136A/15.4V @ 60%
• Setting range: 15 – 70 A (120 V), 105A/14.2V @ 100%
15 – 160 A (240 V) • Wire dim.: - Mild steel & stainless steel: 0.6 – 1.0mm (.023" –.039")
• Efficiency at maximum current: 83% - Aluminum & cored wire: 0.6 – 1.0mm (.023" –.039")
• Max. spool diameter: 100mm & 200mm (4" & 8")
VCT-0384-0944 $1333 65 VCT-0384-2580 $574 55 VCT-0384-2698 $718 85
G150 – Light Duty Cutting & Medalist® 250 CLASSIC – Medalist® 350 CLASSIC –
Welding Portable Tote Outfit Medium Duty Cutting & Welding Outfit Heavy Duty Cutting & Welding Outfit
• Cuts up to 1/4" (6.4mm) or up to • Cuts up to 1/2" (12.7mm) or up to • Cuts up to 3/4" (19.1mm) or up to
5" (127mm) with optional tips 5" (127mm) with optional tips 6" (152.4mm) with optional tips
• Welds up to 5/64" • Welds up to 5/64" (2mm) or up to • Welds up to 1/8" (3.2mm) or up to
(2mm) or up to 1.25" (31.8mm) with optional nozzles 3" (76.2mm) with optional nozzles
1" (25.4mm) with
optional nozzles
• Tanks are
delivered
empty
